Monitor Audio Radius 90 Bookshelf Speakers - R90SW
R90SW
$789 / Pair
Scheduled Delivery
Monitor Audio Radius 90 Bookshelf Speakers - R90SW
R90SW
$789 / Pair
- CATEGORY: Bookshelf Speakers
For ultra-discreet sound all around the home, or partnered with the Radius 380 sub for explosive stereo, the original hi-fi mini monitorcontinues to evolve,incorporating a 4" C-CAMbass driver and 1" C-CAM tweeter.
Technology
- 4" C-CAM bass driver - Radius featuresbass drivers with concave cone profiles, introduced byour top-of-the-range Platinum speakers and applied subsequentlyto Gold GX. Extensive research and FEA modelling have allowed us to perfect the relationship between the radiating diaphragm and its motor design, introducing largermotor sizes and voice coils for increased excursion, higher powercapability and reduced distortion.
- C-CAM Gold Dome tweeter -optimisedto deliver the finest and widest performance within the compactRadius cabinets. It benefits from a more efficient rear-ventingdesign, releasing air trapped and compressed at the back ofthe tweeter dome, and guiding it around the drive assembly toa rear-loading chamber.
- HiVe II port design -Straight from Platinum’s design blueprint, the HiVe reflex portmakes its Radius debut. It’s shaped to have the same effect onairflow as a gun-barrel on a bullet. Rifled grooves inside the porthelp to accelerate the flow and reduce turbulence, so air movesin and out of the port more efficiently, for a faster more dynamicbass response.
- Single through-bolt driver fixing provides mechanical de-coupling and enhanced mid-band clarity and resolution. The through-bolts also act as rigid cross bracing to give a very solid non-resonant cabinet.
- Single point ¼” x 20TPI wall fixing. Use the optional Monitor Audio speaker mount or anystandard wall bracket
- Optional floor-stand with internal (pre-wired) cable management system.
| Specifications | |
|---|---|
| Pre-Construction Bracket | Optional - Monitor Audio Speaker Mount (MASM) |
| Sold As | Pair |
| Weight | 2.1 kg (4 lb 10 oz) |
| Cabinet Dimensions (Including Grille and Bracket (H x W x D)) | 198 x 125 x 203 mm (713/16 x 415/16 x 8") |
| Cabinet Dimensions (Including Grille and Terminals (H x W x D)) | 198 x 125 x 164 mm (713/16 x 415/16 x 67/16") |
| Drive Unit Complement | 1 x 4" (100 mm) C-CAM cone bass/mid driver 1 x 1" (25 mm) C-CAM Gold Dome tweeter |
| Cabinet Dimensions (H x W x D) | 198 x 125 x 140 mm (713/16 x 415/16 x 51/2") |
| Bass Alignment | Bass reflex - Rear ported |
| Power Handling (RMS) | 75 W |
| System Power Handling (RMS) | 100 W |
| Maximum SPL | 102 dBa |
| Recommended Amplifier Requirements | 30 — 100 W |
| Frequency Response | 80 Hz — 35 kHz |
| Sensitivity (1W@1M) | 83 dB |
| Nominal Impedance | 8 ohms |
